Bionic Quadruped Robot

MagicDog

Your first intelligent companion.

The first quadruped robot dog

That can express emotions autonomously

Built in magiclab emotional interaction system, giving magicdog "vitality"

Support omni-directional perceptual interaction of voice, vision and touch

Respond to your emotions anytime, anywhere

The First Quadruped Robot with Emotional Expression

The first quadruped robot dog

That can express emotions autonomously

Built in magiclab emotional interaction system, giving magicdog "vitality"

Support omni-directional perceptual interaction of voice, vision and touch

Respond to your emotions anytime, anywhere

Intelligent AI SAGE Algorithm

Endows MagicDog with the ability for independent thinking and autonomous behavior.

It can perceive complex environments in real-time and make autonomous decisions.

From emotional companionship to task execution, every encounter is more understanding and considerate.

Precise Target Locking, Intelligent Following

Utilizes a TOP-DOWN approach to achieve target detection, recognition, and continuous tracking.

Combining depth cameras to obtain three-dimensional coordinates of targets, dynamically adjusting follow speeds for smooth interactions.

All-Terrain Walking, Superior Obstacle Navigation

Single-line LiDAR, stereo cameras, and RealSense technology work in conjunction to accurately identify seven categories of obstacles.

Possesses active obstacle overcoming capabilities, flexibly adapting to uneven terrains like slopes and gravel paths.

Maximum climb height of 15 cm and maximum incline angle of 40°.

High-Degree Freedom Body Design, Master Of Various Stunts

Features 13 Joint Degrees Of Freedom, Equipped With Low-Noise, High-Torque Electric Motors In The Joints.

Can Perform Over 30 High-Difficulty Poses Such As Backflips, Moonwalks, Handshakes, And Stretching.

Equipped With 4k Hd Lens, One-Click Photography

Can capture photos and videos through the camera mounted on MagicDog's head, offering a dog's perspective of the world while capturing every precious moment.

Free Programming, Infinite Creativity

Graphical programming that is simple and intuitive, making every creation full of more possibilities.

MagicLab Quadruped Robotic

MagicDog

	Specifications	MagicDog PRO	MagicDog EDU
Mechanical Parameters	Dimensions (Standing: H × W × D)	670350560mm	670350560mm
	Dimensions (Lying Down: H × W × D)	720440290mm	720440290mm
	Net Weight (Excluding Battery)	15.8kg	15.8kg
	Actuator Type	High Power Density Actuation Unit	High Power Density Actuation Unit
	Maximum Joint Torque	Approx. 37.5N·m	Approx. 37.5N·m
	Degrees of Freedom (DOF)	13	13
	Aluminum Alloy Precision Joint Motor	12	12
	Joint Range of Motion (Torso)	-37.0°~45.0°	-37.0°~45.0°
	Joint Range of Motion (Thigh)	-207.5°~72.5°	-207.5°~72.5°
	Joint Range of Motion (Shank)	-143.0°~-30.0°	-143.0°~-30.0°
	Maximum Speed	3.0m/s	3.0m/s
	Maximum Payload	10kg	10kg
	Maximum Obstacle Height	15cm	15cm
	Maximum Climbing Angle	40°	40°
Electrical Parameters	Maximum Power	3200W	3200W
	Voltage	22V-36V	22V-36V
	Basic Computing Power	8-Core High-Performance CPU	8-Core High-Performance CPU
	MIC Array	●	●
	Sensors	2D LiDAR + Dual Camera + Depth Camera + 4K HD Camera + Fisheye Camera + Ultrasonic Sensor	2D LiDAR + Dual Camera + Depth Camera + 4K HD Camera + Fisheye Camera + Ultrasonic Sensor
Accessories	Battery	29.6V 8200mAh 240.7W Fast Release	29.6V 8200mAh 240.7W Fast Release
	Adapter	33.6V 3.5A 149W	33.6V 3.5A 149W
	Battery Charging Dock	●	●
Others	Smart Following	●	●
	Emotion Engine	●	●
	Head-Torso Coordination	●	●
	All-Terrain Mode	●	●
	Motion Imitation	●	●
	Human Recognition	●	●
	Patrol Mode	●	●
	Smart Obstacle Avoidance	●	●
	Graphical Programming	●	●
	Acrobatic Movements	●	●
	Facial Expression Display	●	●
	Lighting Display	●	●
	AI Voice Interaction[1]	●	●
	Touch Interaction	●	●
	Photo and Video	●	●
	Real-time Transmission	●	●
	Battery Life	1.5-3.0h	1.5-3.0h
	SDK Support[2]	○	●
	OTA Upgrade	Support	Support
	Carrying Handle	●	●

[1] AI Voice Interaction: Refers to offline voice interaction and commands, voice intercom, music playback and large language model (LLM) conversations, which may require a paid subscription to access LLM dialogues.

[2] For detailed features, please refer to the secondary development manual.

*Maximum speed, maximum payload, maximum slope angle and endurance are measured under laboratory conditions.

*The above parameters may vary in different application scenarios, with different model configurations, or in actual use. Please refer to real performance.
